Technical specification

The major difference between the P67 Performance and P67 Professional, flagship of the ASRock Fatal1ty series, is the presence of a single PCI Express slot instead of the three ones of the P67 Professional. This implies no support for SLI and Crossfire, a lack that makes it theoretically less suited to gaming than many motherboards that implement both slots made available by the two PCI Express 2.0 x8 link of Sandy Bridge. However, there are many high-end video cards or dual GPUs that are able to achieve great performance in videogames, then this mainboard is still a great choice for those who do not need to install more than one video card. Other important differences are in power, with a half number of phases and the absence of the Digital PWM control. We also have 4 USB 3.0 ports less and 4 6Gb/s SATA ports less.The P67 Performance does not rely on the Marvell controller to get the additional 4 6Gb/s SATA port, absence altogether negligible due to the poor performance of the Marvell controller.The features and layout of the P67 Performance mimics in many respects those of P67 Pro3.

Here are the detailed specifications of the P67 Performance Fatal1ty.

CPU

2nd Gen Intel Core i7 / i5 / i3 Socket LGA 1155 supportAdvanced structure of the power phases V8Intel Turbo Boost Technology 2.0 supportIntel K-Series unlocked CPU supportHyper-Threading Technology support

Chipset

Intel P67

Memory

Dual Channel Memory support4 x DDR3 DIMM slotsDDR3 2133 (OC) / 1866 (OC) / 1600/1333/1066 Non-ECC, unbuffered memoryMaximum system memory: 32GB *Intel XMP (Extreme Memory Profile) support

BIOS

64Mb AMI UEFI Legal BIOS with GUI support"Plug and Play" supportCompatible with ACPI 1.1 wake up eventsJumperFree supportSMBIOS 2.3.1 supportDRAM, PCH, CPU PLL, VTT, VCCSA

Audio

7.1 CH HD Audio with content protection (Realtek ALC892 Audio Codec)Premium Blu-ray audio support

LAN,

PCIE x1 Gigabit LAN 10/100/1000 Mb/sRealtek RTL8111EWake-On-LAN supportLAN cable detection supportEnergy Efficient Ethernet 802.3az supportPXE support

Expansion Slots

1 x PCI Express 2.0 x163 x PCI Express 2.0 x13 x PCI slots

SATA3

2 x 6.0Gb/s SATA3 connectors, RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ, AHCI and "Hot Plug" support

USB 3.0

2 x rear USB 3.0 ports by Etron EJ168A, USB 1.0/2.0/3.0 up to 5Gb/s support

Connectors

2 x 6.0Gb/s SATA3 connectors, RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ, AHCI and "Hot Plug" support2 x 6.0Gb/s SATA3 connectors1 x ATA133 IDE connectors (supports 2 IDE devices)1 x Floppy port1 x infrared module header1 x COM port header1 x plug HDMI_SPDIF1 x IEEE 1394 header1 x Power LEDCPU / Chassis / Power Fan connectors24-pin ATX power header8-pin ATX 12V connectorInternal audio connectorsFront panel audio connectorManifold 3 x USB 2.0 (supports 6 ports USB 2.0)X 1 Dr LED Debug

Back Panel I/O

1 x PS/2 mouse1 x PS/2 keyboard1 x Coaxial SPDIF Out port1 x Optical SPDIF Out Port5 x USB 2.0 ports already integratedFatal1ty 1 x Mouse Port (USB 2.0)1 x plug eSATA32 x USB 3.0 ports already integrated2 x RJ-45 LAN ports with LED (LED / action link and speed LEDs)1 x cleaning CMOS switch with LEDHD Audio Connector: Speaker Side/cash back/center speaker/bass/line/Front Speaker/Microphone

Unique Features

F-StreamInstant BootInstant FlashUSB XfastAPP ChargerSmartViewHybrid Booster:
